This workshop focuses on creating detailed architectural designs using BIM, Rhino, Grasshopper, and AI for modular architecture and aggregation.

00:00

Overview
Content
Instructors
Reviews

Date:

Apr 26, 27 - May 3, 4, 2025

Duration:

16 Hours

Difficulty:

Intermediate

Language:

English

Certificate:

Yes

Registration:

€230.00

Tutor:

Albert Sumin

Members:

195.50 EUR (27.59%) discount

Recordings:

Available Indefinitely

Gift Course

Introduction of the workshop:

This workshop focuses on the workflow of creating a detailed conceptual design. We will look at how to combine different tools and technologies, applying them in the most efficient way for those really useful tasks. We will utilize BIM, SUBD, and Aggregation techniques in Revit, Rhino, Grasshopper, and AI. The most important task for us will be integrating all these tools into a single smooth workflow.

What You’ll Learn?

Project organization using BIM technology

Generating modular structures in Rhino+Grasshopper with Monoceros and Wasp

Utilize Rhino.Inside to transfer geometry and parameters from Rhino to Revit and vice versa

Rendering and post-processing in ComfyUI and Photoshop

BIM & Rhino.Inside for Advanced Modular Design

Methodology:

This workshop will build a detailed 3D model in which relatively simple geometry will be created directly in BIM (Autodesk Revit Families), while geometrically complex parts will be generated in Rhino and Grasshopper with Wasp and Monoceros Pro plugins. We will use Rhino.Inside to provide a direct connection between the different project environments.

In this workshop, we will focus on modular architecture to highlight the comprehensive capabilities of aggregation algorithms and BIM technology. We will develop several modules and combine them into complex architectural structures by using aggregation techniques in Grasshopper.

Program of the Workshop

Day 1 - April 26th

Workshop Overview
Short introduction about the overall workflow that we will use during the workshop.
Lecture: Project Organization Using BIM Technology
This lecture will introduce the BIM workflow for projects that feature complex shells or other sophisticated building components. It will also demonstrate examples of projects where this approach has been used.
Revit: Preparing Templates, Families, and Empty Models for Further Project Development
This is the organizational part that precedes any project.

Day 2 - April 27th

Rhino + Grasshopper: Developing Modules
This section will focus on programming and modeling separating parts of modular structures. We will use Grasshopper and SUBD modeling techniques to create geometry suitable for the next steps of our workflow.
Rhino + Grasshopper: Intro to Aggregation Methods
Understanding rules and scripting approaches for aggregation.

Day 3 - May 3rd

Rhino + Grasshopper: Aggregation
This section will focus on using aggregation algorithms with Wasp and Monoceros to finalize the conceptual structure.
Rhino.Inside: Analytical Model and Parameters
To create a proper BIM model, it is not enough to just export geometry from Rhino to Revit. It is necessary to match Rhino geometry with Revit families and assign several parameters like family type, material, workset… on each element. This section will focus on all these aspects.

Day 4 - May 4th

Rhino.Inside: Creating Final Model
This section will focus on Revit and Rhino.Inside. We will transfer previously developed modular structures into the BIM environment.
Rendering and Post-Processing with AI + Photoshop
This section will focus on the ComfyUI + Photoshop workflow for producing final renders of the project.

What You’ll Use?

Highlights:

Content

Introduction + PAACADEMY Updates (07:13)

Modular Design Integration (27:48)

From Rhino to Revit Workflow

This session introduces the tools, software workflows, and plugin setups for modular aggregation, Rhino.Inside, and AI-based visualization processes used in computational design and BIM workflows.

Project Demonstrations & Workflows (53:43)

Project-Based Rhino to Revit Workflows

This session demonstrated advanced workflows combining Rhino, Grasshopper, Revit, and Navisworks through real-world project examples, highlighting techniques for modeling complex geometries and managing large-scale BIM data.

Rhino Grasshopper Aggregation Setup (54:05)

Monoceros in Rhino

This session introduces Monoceros, Rhino 8 interface setup, display mode optimization, Grasshopper template customization, and initial aggregation system logic for modular design.

Modular Aggregation in Grasshopper (43:41)

Building Modular Systems in Grasshopper

This session focuses on constructing modules, organizing slots, and defining connection rules for modular aggregation in Grasshopper, while also addressing data structures and workflow preparation for architectural applications.

Module Connection Rules (48:34)

Modular Aggregation with Connection Rules

This session explained how to manually define and refine module connection rules, use attractors to create voids in modular structures, and prepare for automatic aggregation using Monoceros and Grasshopper workflows.

Rhino Grasshopper Modular Aggregation (39:49)

Modular Aggregation with Rhino Grasshopper

This session explains key Revit family concepts while demonstrating how to create modular aggregation geometry using SubD modeling in Rhino and Grasshopper.

SubD Form Development Strategies (40:51)

Advanced SubD Techniques for Architecture

This session provides an in-depth demonstration of SubD modeling principles in Rhino, illustrating techniques for geometric refinement, modular form development, and preparation for parametric workflows in Grasshopper.

Modular Aggregation with Wasp (39:35)

Building Modular Systems in Grasshopper

This session explores setting up modular components for aggregation workflows in Grasshopper using the Wasp and Elephant plugins, demonstrating advanced methods for managing connectors, geometric attributes, and extracting structured data from Rhino layers.

Wasp Aggregation System (52:47)

Building Aggregations with Wasp

This session explores how to create and control aggregation systems in Wasp by merging parts, generating rules, assigning connector types, and visually analyzing results to optimize modular assemblies.

Modular Unit Setup & Connectors (57:49)

Modular Unit Assembly & Parameter Configuration

This session covers setting up modular container parts, defining connectors, assigning parameters for aggregation, and organizing the structure for Revit transfer.

Rhino-Inside Revit Integration (58:55)

Rhino to Revit workflow demonstration

This session demonstrates how to transfer geometry from Rhino to Revit using Rhino.Inside, including both simple and complex templates for exporting materials and attributes, along with setup tips for files, units, and coordinate systems.

Grasshopper to Revit Workflow (33:25)

Parametric Attributes & Revit Integration

This session demonstrates how to define geometry attributes, assign material and connector types, and prepare parametric components in Rhino and Grasshopper for streamlined aggregation and Revit integration.

Wasp Modular Assembly (33:25)

Mirrored Parts & Adjacency Rules

This session walks through creating mirrored parametric parts, assigning adjacency rules, and managing geometry and connectors in Grasshopper using Wasp for modular architectural aggregation.

Aggregation Techniques (52:59)

Wasp Aggregation Strategies in Grasshopper

This session dives into building modular systems using Wasp in Grasshopper, emphasizing aggregation strategies, tile setup, and data-driven component control for complex design assemblies.

Wasp Connector Aggregation (54:40)

Connector Logic in Wasp Aggregation

This session dives into setting up connector geometry and defining adjacency rules in Wasp, enabling precise control over how modular parts interact in Grasshopper.

Multi-Floor Module Aggregation (48:21)

Connector-based parametric floor aggregation

This session demonstrates how to use Wasp in Grasshopper to generate core modules, configure connector rules, and implement parameter-driven aggregation logic to place, stack, and differentiate architectural parts across multiple floors within a modular building system.

Parametric Wall Aggregation (35:55)

Smart Clustering & Modular Aggregation

This session builds a smart attribute system in Grasshopper using clusters to differentiate wall types and geometries in a modular design, then applies rule-based aggregation logic in Wasp to assemble a multi-story architectural structure.

Parametric Modular Floor Aggregation (54:52)

Wasp-Driven Multi-Story Design

This session covers the creation of parametric multi-story buildings using Wasp in Grasshopper, detailing connector-based aggregation rules & smart attribute-driven geometry placement.

Attribute-Driven Revit Generation (40:16)

Smart Aggregation for Revit

This session explores using smart attribute-based logic in Grasshopper and Wasp to generate Revit-ready components by analyzing module connectivity and dynamically assigning geometry.

Revit Geometry Automation Workflow (22:18)

Modular Systems for Revit Integration

This session provides a complete workflow for generating Revit-ready architectural systems—including concrete walls, glass elements, terraces, and stairs—using Grasshopper logic, smart parameter tagging, surface orientation correction, and Python scripting.

Rendering with ComfyUI (39:45)

AI-Powered Rendering for Architecture

This session focuses on rendering modular geometries using ComfyUI and ControlNet, covering image preprocessing, prompt tuning, high-quality output settings, and debugging techniques.
